Model NO.	CAS-2000D
HS Code	90185000
Production Capacity	1000PCS/Year

Product Description

China ophthalmic AB ScanModel:CAS-2000DTechnical Data
Ophthalmic AB Scan, ophthalmic equipmentCAS-2000D A/B Scan with normal, vitreous body enhancement, retina observation mode, mainly used for diagnosis of intraocular diseases, display the location, shape range of the focus of infection and the relationship with the surrounding tissue. Can be diagnosed vitreous opacity, retinal detachment, eye base tumors etc. eye diseases. A scan is used to measure anterior chamber depth, lens thickness, axial length, calculate diopter of implant IOL as well.B scan:Frequency: 10MHz/20MHz (optional) ,Magnetic driven, noiselessScanning Mode: Sector ScanningMagnify:Multi continuous magnification,Real-Time magnificationResolution: Lateral ≤0.3mm; Vertical≤0.2mmGeometry position precision: Lateral ≤10%; Vertical≤5%Depth:60mmEnhance the part of vitreous body and retinaGain of probe:30dB-105dBScanning Angle:53°Gray Scale: 256False Color: Multi colors. OCTmeasurement type: multigroup distances, perimeters and areasImage postprocessing: multiple curves processing, Pseudo-color processing curveMovies: 100 images movie review, AVI JPG format image outputA scan:Frequency:10MHz, with LEDDepth: 40mmPrecision:±0.05 mmMeasurement: Anterior chamber depth, lens thickness, vitreous body length, total length and averageEye mode: Phakic / Aphakic / Dense / Various IOLIOL Formula: SRK-II, SRK-T, HOFFER-Q, HOLLADAY,BINKHORST-II, HAIGISStat. Calculation: Average and standard deviationStore: 10 Scanning results for each eyeOthers:Display Mode :B, B+B, B+A, AHint: preset keywordCase Search:Multi-keywordsScreen: 15 inch LCDBuilt-in battery: can use 4 hoursUser-defined report template poor credit secured loans

A scan Frequency	10MHz, with LED
Depth	40mm
Precision	±0.05 mm
Measurement	Anterior chamber depth, lens thickness, vitreous body length, total length and average
Eye mode	Phakic / Aphakic / Dense / Various IOL
IOL Formula	SRK-II, SRK-T, HOFFER-Q, HOLLADAY,BINKHORST-II, HAIGIS Stat. Calculation: Average and standard deviation
Store	10 Scanning results for each eye
